Stihl RE 170 PLUS User Manual

0458-663-0121-A
17
English 8 Connecting to a water source
7.4.2 Removing the spray lance
► Squeeze spray lance (1) and spray gun (2) together and
twist as far as they will go.
► Pull spray lance (1) and spray gun (2) apart.
7.5 Attaching and removing the nozzle
7.5.1 Attaching the nozzle
► Push nozzle (1) onto the spray lance (2).
► Twist nozzle (1) until it locks into position.
► If it is difficult to slide the nozzle (1) into the spray lance:
Grease the gasket on the nozzle (1) with a fitting grease.
7.5.2 Removing the nozzle
► Press nozzle (1) and spray lance (2) together and turn
until stop.
► Pull nozzle (1) and spray lance (2) apart.
8.1 Connecting the pressure washer to the water
supply
Connecting the water filter
If the pressure washer is operated with sandy water or water
from cisterns, a water filter must be connected to the
pressure washer. The water filter filters sand and dirt out of
the water and thus protects the components of the pressure
washer from damage.
Depending on the market, the water filter may be included
with the pressure washer.
0000-GXX-4351-A0
2
1
2
1
0000-GXX-9849-A0
8 Connecting to a water source
2
1
0000-GXX-9850-A0

Stihl RE 170 PLUS Specifications

General

Form factor	Upright
Hose length	- m
Cable length	5 m
Power source	Electric
Product color	Black, Orange
Pump material	Aluminum
Detergent tank	-
Maximum flow rate	648 l/h
Minimum flow rate	570 l/h
Sound power level	85 dB
Vibration emission	2.4 m/s²
Working pressure (max)	180 bar
Working pressure (min)	150 bar
Maximum water temperature	60 °C
AC input voltage	230 V
Power consumption (typical)	- W

Weight and Dimensions

Weight	31000 g
