Stihl RE 170 PLUS User Manual

0458-663-0121-A
28
English 15 Cleaning
15.2 Cleaning nozzle and spray lance
► Rinse nozzle and spray lance under running water and dry
with a cloth.
► If the nozzle is clogged: Clean the nozzle with the cleaning
pin.
15.3 Cleaning the water intake screen
► Unscrew the connector (1) of the water connection.
► Pull water intake screen (2) out of the water connection.
► Rinse out the water intake screen (2) under running water.
► Insert water intake screen (2) into water connection.
► Attach the connector (1) and tighten it by hand.
15.4 Cleaning the water filter
The water filter must be disassembled to clean it.
► Remove gasket (1) from the fastener (2).
► Unscrew fastener (2) from filter housing (5).
► Remove gasket (3) from the fastener (2).
► Remove filter (4) from the filter housing (5).
► Rinse gaskets (1 and 3), fastener (2) and filter (4) under
running water.
0000-GXX-9851-A0
0000-GXX-4370-A0
2
1
0000-GXX-9858-A0
5
1
0000-GXX-4373-A0
2
3
1
4

Stihl RE 170 PLUS Specifications

General

Form factor	Upright
Hose length	- m
Cable length	5 m
Power source	Electric
Product color	Black, Orange
Pump material	Aluminum
Detergent tank	-
Maximum flow rate	648 l/h
Minimum flow rate	570 l/h
Sound power level	85 dB
Vibration emission	2.4 m/s²
Working pressure (max)	180 bar
Working pressure (min)	150 bar
Maximum water temperature	60 °C
AC input voltage	230 V
Power consumption (typical)	- W

Weight and Dimensions

Weight	31000 g
