Stihl RE 170 PLUS User Manual

0458-663-0121-A
32
English 19 Specifications
18.2 Greasing the gaskets
► Grease gaskets (1) with grease for fittings.
19.1 Pressure washer STIHL RE 150 PLUS
Version 230 V / 50 Hz
– Fuse (characteristic "C" or "K"): 13 A
– Power consumption: 2.9 kW,
– Maximum permissible mains impedance: 0.32 Ohm
– Electrical protection class: I
– Degree of electrical protection: IPX5 (protection from
water jets in any direction)
– Working pressure (p): 14 MPa (140 bar)
– Max. permissible pressure (p max.): 18 MPa (180 bar)
– Max. water supply pressure (p in max.): 1 MPa (10 bar)
– Maximum water throughput (Q max): 10.2 l/min (612 l/h)
– Minimum water throughput (Q min): 9.0 l/min (540 l/h)
– Maximum recoil force: 21 N
– Max. suction lift: 0.5 m
– Max. water temperature in pressure mode
(t in max): 60 °C
– Max. water temperature in suction mode: 20 °C
– Dimensions
– Length: 383 mm
– Width: 380 mm
– Maximum height: 981 mm
– Minimum height: 792 mm
– Length of high-pressure hose: 12 m
– Weight (m) with accessory attached: 31 kg
Version 230 V / 50 Hz (GB)
– Fuse (characteristic "C" or "K"): 13 A
– Power consumption: 2.8 kW
– Maximum permissible mains impedance: 0.32 Ohm
– Electrical protection class: I
– Degree of electrical protection: IPX5 (protection from
water jets in any direction)
– Working pressure (p): 12.8 MPa (128 bar)
– Max. permissible pressure (p max.): 18 MPa (180 bar)
– Max. water supply pressure (p in max.): 1 MPa (10 bar)
– Maximum water throughput (Q max): 10.2 l/min (612 l/h)
– Minimum water throughput (Q min): 9.5 l/min (570 l/h)
– Maximum recoil force: 20 N
– Max. suction lift: 0.5 m
– Max. water temperature in pressure mode
(t in max): 60 °C
– Max. water temperature in suction mode: 20 °C
– Dimensions
– Length: 383 mm
– Width: 380 mm
– Maximum height: 981 mm
– Minimum height: 792 mm
– Length of high-pressure hose: 12 m
– Weight (m) with accessory attached: 31 kg
19 Specifications
1
1
1
0000-GXX-9852-A0

Stihl RE 170 PLUS Specifications

General

Form factor	Upright
Hose length	- m
Cable length	5 m
Power source	Electric
Product color	Black, Orange
Pump material	Aluminum
Detergent tank	-
Maximum flow rate	648 l/h
Minimum flow rate	570 l/h
Sound power level	85 dB
Vibration emission	2.4 m/s²
Working pressure (max)	180 bar
Working pressure (min)	150 bar
Maximum water temperature	60 °C
AC input voltage	230 V
Power consumption (typical)	- W

Weight and Dimensions

Weight	31000 g
