Stihl RE 170 PLUS User Manual

0458-663-0121-A
26
English 12 After Finishing Work
► Empty detergent container (3) and insert it into the
pressure washer.
► Insert fan-jet nozzle (4) or rotary nozzle (5).
► Wind up the high-pressure hose (6) evenly distributed.
► Store the spray attachment in the holders (7) on the
pressure washer.
12.2 Protecting the pressure washer with antifreeze
If the pressure washer cannot be protected from frost during
transport or storage, the pressure washer should be
protected by a glycol-based antifreeze. The antifreeze
prevents water inside the pressure washer from freezing and
causing damage to the pressure washer.
► Remove spray lance
► Connect the shortest possible water hose to the pressure
washer.
The shorter the water hose, the less antifreeze is needed.
► Mix the antifreeze as described in the antifreeze
Instruction Manual.
► Pour antifreeze into a clean container.
► Insert water hose into container of antifreeze.
► Squeeze and hold spray gun trigger.
► Switch on pressure washer.
► Hold down spray gun trigger until an even jet of antifreeze
is delivered from the spray gun and point the spray gun
into the container.
► Press and release spray gun trigger several times.
► Switch off pressure washer and unplug mains plug from
the socket.
► Detach spray gun and water hose and allow antifreeze to
run into the container.
3
0000-GXX-9853-A0
5
4
0000-GXX-9840-A0
6
0000-GXX-9841-A0
7
7
7
7
7
7
0000-GXX-9842-A0

Stihl RE 170 PLUS Specifications

General

Form factor	Upright
Hose length	- m
Cable length	5 m
Power source	Electric
Product color	Black, Orange
Pump material	Aluminum
Detergent tank	-
Maximum flow rate	648 l/h
Minimum flow rate	570 l/h
Sound power level	85 dB
Vibration emission	2.4 m/s²
Working pressure (max)	180 bar
Working pressure (min)	150 bar
Maximum water temperature	60 °C
AC input voltage	230 V
Power consumption (typical)	- W

Weight and Dimensions

Weight	31000 g
