19 Specifications
18.2 Lubricating the seals
► Grease the seals (1) with grease for fittings.
19.1 Pressure washer STIHL RE 95
Version 220 V to 240 V / 50 Hz
– Fuse (characteristic "C" or "K"): 10 A
– Power consumption: 1.8 kW
– Electrical protection class: II
– Degree of electrical protection: IPX5 (protection from
water jets in any direction)
– Working pressure (p): 10 MPa (100 bar)
– Max. permissible pressure (p max.): 12 MPa (120 bar)
– Max. water supply pressure (p in max.): 1 MPa (10 bar)
– Max. water throughput (Q max): 8.6 l/min (516 l/h)
– Max. suction lift: 0.5 m
– Max. water temperature in pressure mode (t in max):
40 °C
– Max. water temperature in suction mode: 20 °C
– Dimensions
– Length: 290 mm
– Width: 330 mm
– Height: 860 mm
– Length of high-pressure hose: 6 m
– Weight (m) with accessory attached: 9.9 to 10.1 kg
19.2 Extension Cords
If an extension cord is used, the cross sectional area of its
conductors must meet the following minimum requirements
– depending on the line voltage and length of the extension
cord:
220 V to 240 V
– Cord length up to 20 m: AWG 15 / 1.5 mm²
– Cord length 20 m up to 50 m: AWG 13 / 2.5 mm²
100 V to 127 V
– Cord length up to 10 m: AWG 14 / 2.0 mm²
– Cord length 10 m up to 30 m: AWG 12 / 3.5 mm²
19.3 Sound and Vibration Levels
The K value for the sound pressure level is 3 dB(A). The
K value for the sound power level is 3 dB(A). The K value for
the vibration levels is 1.5 m/s².
– Sound pressure level L
pA
measured according to
EN 60335-2-79:
– 220 V / 50 Hz version: 80 dB(A)
– 230 V / 50 Hz version: 80 dB(A)
– 240 V / 50 Hz version: 80 dB(A)
– Sound power level L
wA
measured according to
EN 60335-2-79:
– 220 V / 50 Hz version: 88 dB(A)
– 230 V / 50 Hz version: 88 dB(A)
– 240 V / 50 Hz version: 88 dB(A)
– Vibration level a
h
measured according to EN 60335-2-79,
spray gun: ≤ 2.5 m/s².
19 Specifications
