RE 98
español
110
Datos técnicos
Modelo: RE 98 RE 98 RE 98 RE 98 RE 98
Datos de la conexión a la
red:
230 V / 1~ / 50 Hz 220 V / 1~ / 60 Hz 120 V / 1~ / 60 Hz 127 V / 1~ / 60 Hz 230 V-240 V /
1~ / 50 Hz
Potencia: 1,7 kW 1,7 kW 1,4 kW 1,4 kW 1,7 kW
Fusible (característica "C"
o"K"): 10A 10A 15A 15A 10A
Z
max
*: 0,4 0,4
Clase de protección: I
Tipo de protección: IP X5
Presión de trabajo: 11 MPa
(110 bares)
10 MPa
(100 bares)
8,5 MPa
(85 bares)
8,5 MPa
(85 bares)
11 MPa
(110 bares)
Presión máx. admisible: 12 MPa
(120 bares)
12 MPa
(120 bares)
10 MPa
(100 bares)
10 MPa
(100 bares)
12 MPa
(120 bares)
Presión máx. de alimenta-
ción de agua: 1 MPa (10 bares)
Caudal de agua de paso
máx.: 440 l/h 440 l/h 405 l/h 405 l/h 440 l/h
Caudal de agua de paso
según EN 60335-2-79: 380 l/h 380 l/h 330 l/h 330 l/h 380 l/h
Altura máx. de aspiración: 0,5 m
Temperatura de afluencia
de agua máx. en servicio
de agua a presión: 40 °C
Temperatura de afluencia
de agua máx. en servicio
de aspiración: 20 °C
Fuerza máx. de retroceso: 15,6 N 14,8 N 12 N 12 N 15,6 N
Longitud, aprox.: 305 mm
Ancho, aprox.: 295 mm
Altura, aprox.: 885 mm
Peso (con equipo de pro-
yección y manguera de
alta presión): 16,2 kg 15,6 kg 15,6 kg 15,6 kg 16,2 kg
Longitud manguera de alta
presión (tejido textil): 6 m, DN 06
