RE 98
português
169
Dados técnicos
Tipo: RE 98 RE 98 RE 98 RE 98 RE 98
Dados de ligação à rede: 230 V / 1~ / 50 Hz 220 V / 1~ / 60 Hz 120 V / 1~ / 60 Hz 127 V/1~/60Hz 230V-240 V /
1~ / 50 Hz
Potência: 1,7 kW 1,7 kW 1,4 kW 1,4 kW 1,7 kW
Proteção por fusível
(característica "C" ou "K"): 10 A 10 A 15 A 15 A 10 A
Z
max
*: 0,4 0,4
Classe de proteção: I
Tipo de proteção: IP X5
Pressão de trabalho: 11 MPa (110 bar) 10 MPa (100 bar) 8,5 MPa (85 bar) 8,5 MPa (85 bar) 11 MPa (110 bar)
Pressão máx. admissível: 12 MPa (120 bar) 12 MPa (120 bar) 10 MPa (100 bar) 10 MPa (100 bar) 12 MPa (120 bar)
Pressão máx. de alimenta-
ção de água: 1 MPa (10 bar)
Caudal máx. de água: 440 l/h 440 l/h 405 l/h 405 l/h 440 l/h
Caudal de água segundo
EN 60335-2-79: 380 l/h 380 l/h 330 l/h 330 l/h 380 l/h
Altura máx. de aspiração: 0,5 m
Temperatura máx. de ali-
mentação de água no
modo de água
pressurizada: 40 °C
Temperatura máx. de ali-
mentação de água no
modo de aspiração: 20 °C
Força de recuo máx.: 15,6 N 14,8 N 12 N 12 N 15,6 N
Comprimento aprox.: 305 mm
Largura aprox.: 295 mm
Altura aprox.: 885 mm
Peso (com equipamento
de injeção e mangueira de
alta pressão): 16,2 kg 15,6 kg 15,6 kg 15,6 kg 16,2 kg
Comprimento da man-
gueira de alta pressão
(tecido têxtil): 6 m, DN 06
*
Impedância de rede máxima admissível na ligação doméstica
