Stihl RMI 522 C User Manual

EN
87
0478 131 8365 C - EN
Rectangular mowing area with one tree
and swimming pool
Docking station:
Location (1) directly next to the house A
No-go area:
Installation around the free-standing
tree (3), based on a linking section
installed at right angles to the edge.
Pool:
For safety reasons (specified wire
clearance), the perimeter wire (2) is routed
around the pool B.
Wire clearances: (Ö 12.5)
Clearance to the edge: 28 cm
Clearance to adjoining area that can be
travelled on (e.g. footpath) with a stepped
area height of less than +/- 1 cm: 0cm
Clearance around the tree: 28 cm
Clearance to the pond: 100 cm
Programming:
No further adaptation is necessary
following definition of the size of the
mowing area.
Points to note:
Unmown areas around the swimming pool
must be mown manually on a regular basis
or cut using a suitable lawn trimmer.
26. Installation examples

Stihl RMI 522 C Specifications

General

Cutting Width	20 in (51 cm)
Battery Type	Lithium-Ion
Cutting Height Adjustment	Central
Sound Power Level	60 dB(A)
Warranty	2 years
Maximum Lawn Area	2100 m²
Slope Capability	40%
Rated Output	1000 W
Engine Type	DC electric motor
Power Output	1000 W
Cutting Height Range	0.8 - 2.4 inches
Vibration Level Left/Right	2.5/2.5 m/s²
