0478-131-3052-A
43
English
11 Installing the Perimeter Wire
To install a search loop in combination with a corridor:
► Install two search loops (1) at an angle of 90° in the part
of the mowing area that can only be reached via a corridor.
► Keep a minimum clearance of a = 6.6 ft. (2 m) from the
corridor entrance.
11.10 Installing Linking Sections
A linking section links a secondary area to the primary
mowing area, e.g. a mowing area in front of and behind the
house that the iMow cannot travel to on its own. This allows
both mowing areas to be mowed automatically.
► Route the perimeter wire (1) parallel and close to one
another.
► Attach the linking section to the ground with a sufficient
number of wire stakes (2).
11.11 Accurate Mowing Along Edges
► Along high obstacles, route the perimeter wire with a
minimum clearance of 13 in. (33 cm) from the obstacle.
This buffer area will be left unmowed.
To avoid the buffer area which will be left unmowed, you can
lay edging stones or pavers around high obstacles, e.g.
walls. The width of the eding stones must be at least
b = 10.2 in. (26 cm).
11.12 Sloping Terrain in the Mowing Area
NOTICE
STIHL recommends that you install the perimeter wire at a
maximum pitch of +/- 10 degrees. The perimeter wire can be
installed up to +/- 15 degrees, but this can require additional
adjustments to the perimeter wire installation. Slopes should
also be noted in the garden sketch.
Maintain a minimum distance of at least 39.4 in. (100 cm)
from water and other potential drop-offs, such as edges and
steps.
