13 Control Panel / Manual Controller Display Information
13.1 Information Area
The following information is shown in the top right corner of
the display:
1. Cellular Signal
The display shows the strength of the cellular signal.
2. Time
The current time is indicated in 24-hour format.
3. Automatic mowing status
4. Charge status
The battery symbol shows the battery's state of charge.
13.2 Status Screens
Different status screens may appear, depending on the
status of the robotic mower.
► Configure the status screen with various information,
@ 14.4.
Status screen when the robotic mower is not in operation
The text "iMow ready for op." and the automatic mowing
status is displayed in the bottom area of the screen.
There are two configurable fields in the top display area.
13 Control Panel / Manual Controller
Display Information
– 4 bars: optimum signal strength
– 1 to 3 bars: medium signal strength
– No bars: no signal
A question mark is shown during initialization of the
module while the unit is acquiring the cellular signal.
A small "x" indicates that there is no Internet
connection.
When automatic mowing is switched on, the
Automatic symbol appears.
– No bars: battery discharged
– 1 to 5 bars: battery partially discharged
– 6 bars: full charge
During charging, the plug symbol is displayed instead
of the battery symbol.
