Stihl TS 500i - Maintenance and Repairs; Disposal

TS 480i, TS 500i
English
51
Abrasive cutting wheels (TS 500i)
Users of this unit should carry out only
the maintenance operations described
in this manual. STIHL recommends that
other repair work be performed only by
authorized STIHL servicing dealers
using genuine STIHL replacement parts.
Genuine STIHL parts can be identified
by the STIHL part number, the
{ logo and, in some cases, by
the STIHL parts symbol K. The
symbol may appear alone on small
parts.
For repairs of any component of this
unit’s air emissions control system,
please refer to the air emissions
systems warranty in this manual.
Observe all country-specific waste
disposal rules and regulations.
STIHL products should be disposed of in
approved disposal sites for recycling.
Contact your authorized STIHL
servicing dealer for the latest information
on waste disposal.
Composite cutting wheels
Minimum outside diameter of
thrust washers:
4.06 in.
(103 mm)
Max. depth of cut: 3.9 in.
(100 mm)
Diamond cutting wheels
Minimum outside diameter of
thrust washers:
4.06 in.
(103 mm)
Max. depth of cut: 3.9 in.
(100 mm)
Outside diameter: 14 in.
(350 mm)
Max. thickness: 0.189 in.
(4.8 mm)
Bore diameter/spindle
diameter:
0.787 in.
(20 mm)
Tightening torque: 22 lbf ft
(30 Nm)
Composite cutting wheels
Minimum outside diameter of
thrust washers:
4.06 in.
(103 mm)
Max. depth of cut: 4.9 in.
(125 mm)
Diamond cutting wheels
Minimum outside diameter of
thrust washers:
4.06 in.
(103 mm)
Max. depth of cut: 4.9 in.
(125 mm)
Maintenance and Repairs Disposal
000BA073 KN
