Dimensions
4.32
Ground clearance with load, center of
wheelbase
m2 (mm) 30 30
4.34
Aisle width with 800 x 1200 mm pallet
along forks
Ast (mm) 2062 2062
4.35 Turning radius Wa (mm) 1390 1390
Performance data
5.1 Driving speed, full load/no load km/h 4.5/5 4.5/5
5.2 Lifting speed, with/without load m/s 0.017/0.024 0.017/0.024
5.3 Lowering speed, with/without load m/s 0.09/0.06 0.09/0.06
5.8
Maximum climbing ability, with/without
load
%6/16 6/16
5.10 Brake type Electric Electric
Driving
6.1 Traction motor rating S2 60 min kW 0.75 0.75
6.2 Lifting motor rating at S3 15% kW 0.5 0.5
6.4 Battery voltage, nominal capacity K5 V/Ah 24/20 24/20
6.5 Battery weight kg 5 5
6.6 Energy consumption acc. to VDI cycle kW/h n/a n/a
Other
8.1 Drive control method DC DC
8.4 Noise level dB(A) <74 <74
Eco-design requirements for
electric motors and variable
speed drives
All motors in this industrial truck are exempt
from Regulation (EU) 2019/1781 because
these motors do not meet the description giv-
en in Article 2 "Scope", Item (1) (a) and be-
cause of the provisions in Article 2 (2) (h) "Mo-
tors in cordless or battery-operated equip-
ment" and Article 2 (2) (o) "Motors designed
specifically for the traction of electric vehicles".
All variable speed drives in this industrial truck
are exempt from Regulation (EU) 2019/1781
Technical Data
6
Eco-design requirements for electric motors and variable speed drives
