6.
4
Battery
voltage /
rated ca-
pacity
V /
Ah
24 / 250 24 / 375 24 / 250 24 / 375
6.
5
Battery
weight (+/-
5%)
kg 212 288 212 288
Other
8.
1
Control
type
Electronic
8.
4
Noise level
in driver's
ear
dB
(A)
<70
If not stated, the values in the table are for
forks where l = 1150 mm and a 24 V / 250 Ah
battery
(1) Excluding versions with standard wheel-
base rod
(2) With fork length l > 1600 mm
3) For other lengths, see the table below
(4) With fork length l > 1600 mm add 4 mm
(5) The values refer to the tiller always active
position rotated 90°
(6) Geometric limit for fork length l≤1600 mm;
geometric limit for fork length l>1600 mm =
24%
(7) For the side-removal version, b1 = 730 mm
Levers with struts
Forks DIN Standard Battery DIN Wide Battery
l cxyl
1
Wa y l
1
Wa
980 500 744 1172 1557 1508 1244 1629 1580
1150 600 914 1342 1727 1678 1414 1799 1750
1450 750 1214 1642 2027 1978 1714 2099 2050
1600 800 1364 1792 2177 2128 1864 2249 2200
dimensions expressed in millimetres
Levers with standard wheelbase rods
Forks DIN Standard Battery DIN Wide Battery
l cxyl
1
Wa y l
1
Wa
Technical data
6
Technical data
