Still OPX 25 PLUS - LTX50 General Overview

LTX50 general overview
2374
1
2
3
4
5
16
15
18
18
8
9
10
17
19
12
13
14
16
6
11
20
21
5
7
22
23
Steering wheel with integrated controls
Drive wheel
Hood for accessing the battery compartment
Motor compartment cover
Battery
Platform damping system
Rear wheels
Tow coupling
Trailer lighting socket
Dashboard
12/24 V cigarette lighter socket
Emergency stop button
1
2
3
4
5
6
7
8
9
10
11
12
On/off key
Digicode - Numerical Keypad
Ballast
Operator platform
Document holder
Glove compartment
Battery plug/socket
Power current plug of the on-board battery
charger
Mechanical battery lock clasp
Seat backrest
LiftRunner system hydraulic coupling
13
14
15
16
17
18
19
20
21
22
23
