Capacity label for tow tractors
(LTX50, LTX-FF, LTX-T) with
front coupling
The label is only present on tractors equipped
with a front tow coupling.
NOTE
The values indicated refer to the towing limits
with the truck in
reverse travel
and must not
be exceeded, otherwise the stability of the
truck and the load-bearing capacity of the
structures may be compromised.
The trailer coupled to the truck must not ex-
ceed the maximum permissible weight of
1000 kg. The maximum permissible pulling
force on the coupling during towing is 800 N.
Qmax=1000 kg
F=800 N
2480
Overview
3
Markings
6945878043344 EN - 11/2021 - 12
