Lift
Types of lift masts (where
present)
Some trucks in the OPX range are equipped
with a lift mast:
●
Simplex (OPX-L20S and OPX-L12/16)
●
Telescopic (OPX-L20 and OPX-L20D)
Simplex (OPX-L20S and OPX-L12/16)
When the "lift" button is pressed, the fork car-
riage is raised to the height h3 by the central
cylinder via a chain.
Telescopic (OPX-L20 and OPX-L20D)
When the "lift" button is pressed, the internal
mast is raised by the lateral cylinders and
drives the fork carriage (h3) via the chains (the
lifting speed of the fork carriage rail is twice
that of the internal mast).
CAUTION
In locations with a low ceiling, be aware that the load
height may be greater than the mast height.
