Still OPX 25 PLUS - Location of Labels LTX-FF

Location of labels LTX-FF
2418
!
1
2
5
18
9
10
12
12
8
GEL
Pb+Sb
13
14
1
11
6
7
17
17
16
15
15
16
4
3
12
19
Qmax=1000 kg F=800 N
1
20
Qmax=5000 kg F=1000 N
"Danger of crushing hands" label
"Operating and maintenance manual" label
Truck capacity label
Warning label
"Yearly safety inspection" label (Germany
only)
"Nominal value" designation plate
Label "ON/OFF"
"Cold store" label (for cold-store equipment
only)
1
2
3
4
5
6
7
8
"Danger of crushing feet" label
"Maximum permissible pressure" label
"Operator platform capacity schematic view"
label
"Hook" symbol
"Battery warning" label
Version set up for gel batteries
"Positioning yourself in front of the truck is
prohibited" label (only in pedestrian mode
with steering wheel option)
9
10
11
12
13
14
15
