Getting started UM0718
12/31 Doc ID 15846 Rev 1
1.4.2 Software configuration
● Install the GUI provided with the package
● Open the GUI (by clicking on Start -> Programs -> STMicroelectronics -> Advanced
PMBus -> Advanced PMBus Software Application) or simply click on the shortcut of
Advanced PMBus Software Application available on the desktop
● Click on File -> Connect option or on Connect icon
● Press the polling button to identify the connected slaves
● The user can now control/monitor the desired slave by clicking on the slave address.
Table 4. PMBus connector
Pin Description
1 Control 5
2 Control 4
3 Control 3
4 Control 2
5 VDD_OUT
6 GND
7 Control 1
8 PMBus Alert
9 PMBus Clock
10 PMBus Data
