2.0 INSTALLATION
2.1 Default PIN code: 0000
2.2 Front panel/underside
Fig.2
NOTE: The graphics are for representation only.
1. Power indicator /remote sensor
2. Speakers
3. Buttons: I nput source, Menu, V-/V+, CH-/CH+, Standby/ON.
4. Power switch ON/OFF
2.3 Rear panel
NOTE: The graphics are for representation only.
2.3.1 43/50/55 i nch
Fig.3b
1. OPTICAL Use an RCA cable to connect your TV to a compatible digital ampli er or
Home theatre set.
2. HDMI 3 Connect HDMI input signal from a signal source such as DVD, Blu-ray player
or game console.
3. HDMI 2 Connect HDMI input signal from a signal source such as DVD, Blu-ray player
or game console.
4. HDMI 1 (ARC) Connect HDMI input signal from a signal source such as DVD, Blu-ray
player or game console or directly to a Digital Ampli er that supports the
ARC function. This input is equipped with the ARC (Audio Return Channel)
feature to implement audio connections and for a full Dolby audio support.
5. VIDEO/AUDIO L/R Connect AUDIO and VIDEO input signals from a signal source such as DVD.
2.4 Side panel
NOTE: The graphics are for representation only.
2.4.1 43/50/55 i nch
Fig.3a
1. SAT IN Connect a satellite dish to the TV for searching programmes.
2. ANT/CABLE IN Connect a terrestrial antenna or cable connection from your provider to the
TV for searching programmes.
3. CI Connect a Conditional Access Module (CAM).
5
English
