20
PART 1 • English
System & Memory
CPU: STi7111
Flash Memory: 8 MBytes
System Memory: 256 MBytes
Connectors
SAT IN; SAT OUT
TV SCART (RGB, CVBS, Audio L/R Output with volume control)
HDMI (V/A-Output) Type A Version 1.0 HDCP 1.1
RCA Output - Audio L/R & Video Output
S/PDIF Out (Coaxial, Optical)
IR Extender input
USB 2.0, Type A Connector
CI+ compatible slot
General Data
Input Voltage Range: 100 - 240 V AC, 50/60 Hz
Power Consumption: max. 20 W, typ. 7.1 W (without external device)
Power consumption in stand-by:
0.83 W (without external device)
Operating Temperature: 0° ~ +40°C
Storage Temperature: -10° ~ +70°C
Operating Humidity Range: 25 - 75%, RH, non-condensing
Size (W × H × D) in mm: 230 x 164 x 40
Weight: 0.82 kg
