EVAPORATOR SECTION ACCESS, CONTINUED: DECK PAN REMOVAL / THERMOMETER
10
Thermometer is located on air return duct (as illustrated
below).
Thermometer reflects internal air temperature only (not
actual food temperature).
Use probe thermometers to determine actual product
temperatures.
Caution! Turn Off Power To Unit Before Removing
Deck Pans! Rotating Fans Can Cause Severe Injury!
Deck pans consist of the pan and finger hole
inserts.
To remove, use finger hole to grasp and lift pans
UP AND OUT of case.
See below illustration.
Deck Pan
Finger Hole
Finger Hole
Deck Pan
Thermometer
Note: Illustration Shown May
Not Exactly Reflect Every
Feature Or Option Of Your
Particular Model.
