CONDENSER PACKAGE EXPLODED PICTORIAL - MODEL MI44RF.7448
Sight Glass
Condensing Coil
(and Internal Fan)
Compressor
Hot Gas Loop
Condensate
Pan / Wicking
Material
Compressor
Electrical Box
Condensate
Overflow Pan
Sight Glass
Compressor
Inverter
Condensing Coil
(and Internal Fan)
Filter Dryer
Filter Dryer
Drain
Illustration Below May Not Reflect Every Feature Or Option Of Your Particular
Case. See Next Page For Alternate Condenser Package Designs.
