CASE START-UP VIA MAIN POWER SWITCH / TEMPERATURE CONTROL 3-WAY SWITCH
7
-
 Remove front panel on control side of unit
(see illustration below).
 Turn on main power switch.
 Main power switch will start evaporator coil
fans, and the compressor motor.
-
 Remove front panel on control side of unit to
access temperature control switch.
 The 3-way switch allows unit to merchandise
product at three (3) separate temperature
settings:
A. Refrigerated packaged PRODUCE products
at 41 °F (5 °C) or less product temperatures.
B. Refrigerated packaged MEAT & DAIRY
products at 38 °F (3.3 °C) or less product
temperatures.
C. FROZEN packaged products at 0 °F
(-18 °C) or less product temperatures.
 See enlarged view of switchbox below.
Model MI44RF (Shown) May
Not Exactly Reflect Every
Feature Or Option Of Your
Particular Model.
