Structural Concepts Oasis MI44RF - Condenser Package Exploded Pictorial - Model Mi46 Rf.7448 and Mi48 Rf.7448

16
CONDENSER PACKAGE EXPLODED PICTORIAL - MODEL MI46RF.7448 AND MI48RF.7448
Illustration Below May Not Reflect Every Feature Or Option Of Your Particular
Case. See Previous Page For Alternate Condenser Package Designs.
Condensing Coil
(and Internal Fans)
Hot Gas Loop
Condensate
Pan / Wicking
Material
Compressor
Electrical Box
Condensate
Overflow Pan
Sight Glass
Compressor
Drain
Filter Dryers
Compressor
Compressor
Electrical Box
