21
1 Rack Light Assembly LH or RH 30 Crumb Tray
2 Upper ABS Shelving 31 Condiment Pan
3 Bulb 32 Rear (Pike) Door, Left or Right Hand Specific
4 Front Air Return 33 Ledge Support Bracket Channel
5 Center Glass Divider 34 Ledge Support Bracket
6 Clam Shell Assembly 35 Baffle Assembly
7 Front Door Assist Gas Cylinder 36 Caster, Refrigeration Assy., Roll Out Pan
8 Honeycomb 37 Embraco® Hermetic Compressor
9 Expansion Valve Access Plate 38 Sight Glass
10 Acrylic Front Air Deflector 39 Filter Drier
11 Fan Motor / Blade / Bracket Assembly 40 Evaporative Wicking Material
12 Side Kick Panel 41 Service Valve, Receiver
13 Leveler 42 Receiver
14 Front Kick Panel 43 Hot Gas Pan
15 Front Panel 44 Roll Out Pan, Refrigeration Assembly
16 Deck Pan 45 Support, Refrigeration Close Off
17 Step Insert 46 Hot Gas Loop
18 Lower End Panel Assembly 47 Electrical Box - Hot Gas Overflow
19 Mirror, Stainless Steel 48 Liquid Level Control
20 Upper End Panel Assembly 49 Fan Blades / Bracket
21 Front Curved Insulated Glass Assembly 50 Condenser Coil
22 Controller Display, Temperature 51 Fan Motor
23 Indicator Light, Hot Pan 52 Electrical Box - Compressor
24
Rocker Switch, Main Power (accessible at un-
derside)
53
25 Contactor 54
26 Toe-Kick, Rear 55
27 Ballasts 56
28 Cover, Rear Wireway 57
29 Rear Ledge 58
PARTS LIST FOR MODEL SB5766.3923/3923A (SIMILAR TO OTHER MODELS)
