SECURITY
Anti-Theft Grid Installation (Optional Item only on Model SB5766)
Position Anti-Theft Grid so that the locking rods extend down pointing towards the floor.
Insert grid extensions into the forward air return louver.
With “U” shackle released from the padlock base, insert the locking “U” of the padlocks through the sta-
tionary locking bracket.
Rotate “U” shackle 90 degrees and pull up through grid; secure “U” shackle into padlock base.
Note: Due to possible design modification, actual Anti-Theft Grid construction and positioning may differ
than depicted below.
Return
Air Grille
Anti-Theft
Grid Extensions
Anti-Theft
Grid
