Struers LaboPol-20 - Adjusting the Force; Manual Preparation

For taller specimens
1. Pull the quick-release
ring and lift the housing.
2. Lift the pressure feet up
as far as possible.
3. Lower the housing back
into position.
A Force indicator
B Force
adjustment
screw
C Pressure foot
7.2.6 Adjusting the force
Hint
Do not use maximum force at the same time as maximum speed.
1. To adjust the force, turn
the force adjustment
screw.
The indications on the
housing correspond to
the actual force in
Newton.
A Force indicator
B Force
adjustment
screw
C Pressure foot
Indication Force
(0) 0 - 5 N
1 10 N
2 20 N
3 30 N
7.2.7 Manual preparation
If you cannot prepare a specimen by using a standard specimen mover plate or specimen holder,
you can prepare it manually.
