Stryker 1020 - Page 86

Transfer System Assembly
85
Item Part No. Part Name Qty.
A 0002−100−000 Pan Hd. Machine Screw 4
B 0025−079−000 Pop Rivet 4
C 0014−021−000 Washer 4
F 0016−003−000 Fiberlock Hex Nut 4
H 0028−093−000 Retaining Ring 8
M 0038−252−000 Extension Spring 2
N (page 88) Board Support Assembly 2
P 1020−001−029 Bearing 4
R (page 86) Transfer Board Ass’y, Left 1
S (page 87) Transfer Board Ass’y, Right 1
T 1020−024−121 Board Retainer 2
W 0004−032−000 Soc. Hd. Cap Screw 2
X 0004−142−000 Soc. Hd. Cap Screw 2
Y 0011−179−000 Nylon Washer 2
Z 0016−028−000 Nylock Nut 2
AA 1020−024−034 Support Plate, Left 1
AB 1020−024−035 Support Plate, Right 1
1020−024−022 No Transfer Board Option
Item Part No. Part Name Qty.
A 0037−074−000 Hole Plug 8
B 0721−031−065 Hole Plug 8
