76
Manual Fowler to Litter Assembly
Hex Hd. Cap Screw
0003−078−000
Nylock Nut
0016−029−000
HEAD END
Assembly part number 1020−032−059 (reference only)
Hex Hd. Cap Screw
0003−078−000
Item Part No. Part Name Qty.
A 1020−032−054 Pivot Leg Assembly 1
B 0003−078−000 Hex Hd. Cap Screw 4
C 1020−032−056 Left Bracket Weldment 1
D 1020−032−055 Right Bracket Weldment 1
E 0014−002−000 Nylon Flat Washer 4
F 0016−028−000 Nylock Nut 6
H 0003−050−000 Hex Hd. Cap Screw 2
