Service Information
BRAKE CAM ASSEMBLY REPLACEMENT
Tools Required:
• Needle Nose Pliers
• Bungee Cords
Procedure:
1. Pump the stretcher all the way up.
2. Raise both siderails to the up and latched position.
3. Using bungee cords, support the raised base hood.
4. Put the base brake/steer pedal in the neutral position.
5. Using needle nose pliers, remove the rue clip and clevis pin that secure the brake cam assembly to the brake rod.
Save all parts for reinstallation.
6. Using needle nose pliers, remove the rue clip and washer from the top bearing pivot support. Save all parts for
reinstallation.
7. Using needle nose pliers, remove the rue clip and plastic washer from the bottom support. Save the rue clip for
reinstallation.
8. Raise the brake cam link off of the brake rod actuator and slowly pull outward on the brake cam assembly. Discard
the brake cam assembly.
9. Reverse steps to reinstall.
Note: When installing the new brake cam assembly, install the bottom slightly first and then push downward and inward
to install under the top bearing.
10. Verify proper operation of the unit before returning it to service.
