This manual is designed to assist you with the operation of Stryker Model 1089 Eye Surgery Stretcher. Read this
manual thoroughly before using the equipment or beginning maintenance on it. To ensure safe operation of this
equipment, it is recommended that methods and procedures be established for educating and training staff on the safe
operation of this stretcher.
PRODUCT DESCRIPTION
The Stryker Model 1089 Eye Surgery Stretcher is a general purpose patient transport and treatment stretcher.
INTENDED USE OF PRODUCT
The Stryker Medical Eye Surgery Stretcher is a non-powered, wheeled device which consists of a platform mounted
on a wheeled frame that is designed to support patients in a horizontal position. The device has siderails and has the
option available to support the temporary or permanent placement of I.V. poles. The Eye Surgery Stretcher provides
the caregiver a method of transporting patients within a healthcare facility and may also be used for minor procedures
and short-term stay (treatment and recovery).
SPECIFICATIONS
Safe Working Load
Note: Safe Working Load
indicates the sum of the patient,
mattress, and accessory weight.
500 lbs. 226.8 kg.
Overall Stretcher Length/Width 90”/31.5” 228.6 cm/80 cm
Minimum/Maximum Stretcher Height 22.25”/34” 56.5 cm/86.4 cm
Fowler Angle 0° to 90°
Gatch Angle (Optional) 0° to 30°
Trendelenburg/Reverse Trendelenburg +18°/-18°
Minimum Under-Stretcher Clearance
6” nominal 15 cm
1.75” under the hydraulic cylinders
and fifth wheel
4.5 cm
Stryker reserves the right to change specifications without notice.
