Stryker 1089 - Release Pedal (Side) Adjustment

Return To Table of Contents
26 1089-009-002 REV B www.stryker.com
RELEASE PEDAL (SIDE) ADJUSTMENT
Tools Required:
• None
Procedure:
1. Manually disengage the release pedal swivel from the release pedal assembly.
2. To increase the release rod engagement with the release valve, turn the release pedal swivel clockwise on the
threaded release rod.
3. To decrease the release rod engagement with the release valve, turn the release pedal swivel counterclockwise
on the threaded release rod.
Note: If the pedal swivel assembly is threaded too far onto the release rod, the release valve will be partially
activated and the jack will drift.
Service Information
