Siderail Operation Guide
1−10
OUTSIDE SIDERAIL CONTROLS
1
2
3
4
5
6 8
7
9
11
10
13
14
12
1. Press to raise the Fowler (back section).
2. Press to lower the Fowler (back section).
3. Press to raise the litter.
4. Press to lower the litter.
5. Press to raise the foot section.
6. Press to lower the foot section.
NOTE
When the bed is at a low height and the foot down button is pressed, the litter may raise automatically to pro-
vide adequate clearance. The “BED UP” LED on the siderail will flash to indicate activation.
7. Press to increase the seat depth (optional function).
8. Press to decrease the seat depth (optional function).
NOTE
If the Fowler (back section) angle is below 35!, pressing the button to decrease the seat depth will cause
the Fowler to raise to 35! before the seat depth decreases. Once the Fowler (back section) is elevated to
35! or greater, the “SKOOCHER ACTIVE” LED will light and the seat depth can be changed.
