SPECIFICATIONS
Imaging System 1/3” Interline Transfer, EX view HAD CCD
768 (H) x 494 (V) pixels
Scanning System 2:1 Interlaced
Horizontal: 15.734 kHz
Vertical: 59.94 Hz
Video Outputs
Composite: One NTSC standard Digital: Two Digital Video Interface (DVI)
1.0V P-P into 75 Ohms 1024X768 XGA resolution
Connector: BNC coaxial Connector: 29-pin DVI-I
Component: Two S-VHS Digital: One Serial Digital Interface (SDI)
Y-1.0V P-P C-0.29V P-P SMPTE-259M
Connector: 4-Pin S-VHS Connector: BNC Coaxial
Resolution
Horizontal: 950 lines
Vertical: 500 lines
Signal to Noise Ratio 72 dB
Mounting Endoscope Eyepiece used with coupler
C-mount camera head used with C-mount scopes
(C-mount 1”-32UN-2A)
Minimum Illumination < 1.0 Lux
Auto Shutter Range 1/60 to 1/50,000 second
Gain
OFF 0 dB
LOW 5 dB
MEDIUM 10 dB
HIGH 15 dB
Operating Temperature 5° to 40°
Transport & Storage
Temperature 5° to 40° C
Relative Humidity 10% to 85%
Atmospheric Pressure 700 hPa to 1060 hPa
Power Consumption approx. 30 W
Input Voltage Range 100/120 VAC 50/60 Hz
Total Shipping Weight 13 lbs (5.9 kg)
Dimensions
Camera Control Unit: 9.8”w x 4.0”h x 15”d (24.8cm w X 10.1cm h X 38.1cm d)
Camera Head Cable
to Camera Control Unit: 10 foot (3m) sealed cable or 21.3 foot (6.5m) sealed cable (sensed by CCU)
Enhancement Switchable to 8 steps
Classification & Approvals Complies with IEC 601-1 with Amendments 1 & 2, CSA Std. c22.2 No. 601.1 - M90, and UL
Std. No. 2601-1
Complies with EN 60601-1-2: 1993 (EMC compliance of medical devices)
Type BF applied part or Type CF applied part as labeled on the product
Class I equipment
Ordinary equipment
Continuous operation
