FUSE REPLACEMENT
INSTRUCTIONS
1. Unplug the camera control unit from the wall socket and
remove the power cord from the camera control unit.
2. Unlatch the fuse holder above the AC Inlet (16) and
remove. You may need to press the tab on the fuse
holder with a slender screwdriver to release the latch.
3. Replace the fuse with the same value and rating.
WARNING To avoid the risk of fire, replace only with a
fuse of the value specified on the fuse label
(located on the rear panel of the camera
control unit).
4. Reinstall the fuse holder until the tab snaps in place.
PERIODIC MAINTENANCE SCHEDULE
WARNING To ensure safe operation of the Model 988
Medical Video Camera you should perform the
following procedure periodically:
Activity: Check earth leakage current to <500µA
(<300µA in U.S.A.), ground impedance to <0.1
ohms, and power consumption less than or
equal to rated power.
When: Every 12 months.
Tools and Equipment Required:
True RMS digital multimeter and safety analyzer.
Refer calibration and operating difficulties not detailed in this
manual to your Stryker Endoscopy sales representative, or
Stryker Endoscopy Customer Service (in the United States:
1-800-624-4422), or the nearest Stryker Endoscopy
subsidiary (refer to the
Other Service
section in this
manual).
