Stryker FL17E - Bed Illustration

Introduction Chapter 1
11
1.9 BED ILLUSTRATION
N
N
O
O
T
T
E
E
Your bed may have plastic siderails. Illustrated below is the FL17E equipped with steel siderails.
Figure 1.9
RESTRAINT STRAP
LOCATIONS
HEAD END
CASING
SIDE MATTRESS
RETAINERS
RESTRAINT STRAP
LOCATIONS
EMERGENCY
CRANK STORED
FOLEY BAG
HOOKS
FOOT END
CASING
EMERGENCY
CRANK SLOTS
IV POLE
HOLDERS
FOOT END
MATTRESS RETAINER
OVERHEAD TRAPEZE
SOCKETS
SIDERAIL OUTER
CONTROL PANEL
PUSH/PULL HANDLES
BRAKE/STEER
PEDAL
FOOT BOARD
CONTROL PANEL
SIDERAIL INNER
CONTROL PANEL
ON/OFF SWITCH
FOWLER
SEAT SECTION
KNEE GATCH
FOOT SECTION
SIDERAIL LATCH
LEVER
FIFTH STEER
WHEEL
