1. INTRODUCTION
This manual is designed to assist you with the operation of the Stryker Model FL17E Acute Care
bed. Read it thoroughly before operating the bed. Hospital staff should be able to refer to this
manual at all time when using the bed.
The Operations Manual is an integral part of the bed and should be included if the bed is sold or
transferred.
1.1 TECHNICAL SPECIFICATIONS *
Maximum Weight Capacity 500 lb (227 kg ) including 100 lb (45.5 kg) of
boards and accessories.
Overall Length/Width:
- siderails up
- siderails down
93 x 42 9/16" (236.2 cm x 108.1 cm)
93 x 38 3/4" (236.2 cm x 98.4 cm)
Overall Bed Weight 433 lb (196 kg)
Sleep surface 35 x 80" (89 to 203 cm) extendable to 82" (208
cm) and 84" (213 cm)
Mattress Size Recommended:
Mattress Thickness:
35 X 80 or 84" (89 X 203 or 213 cm)
5 to 6 1/2" (13 to 16 cm)
Minimum/Maximum Bed Height 14 to 29" (35.5 to 73.7 cm)
Sound Level
< 58 dBa
Fowler Angle 0 to 65°
Knee Gatch Angle:
w/o Auto Contour Positioning
w/Auto Contour Positioning
0 to 32°
0 to 24°
Trendelenburg/Reverse Trendelenburg -14 to +14°
Electrical Requirements - All electrical
requirements meet UL 544 specifications.
100 V~, 50-60 Hz, 6.3 A
120 V~, 50-60 Hz, 4.8 A
120 V~, 50-60 Hz, 9.8 A w/auxiliary outlet
200 V~, 50-60 Hz, 3.2 A
220 V~, 50-60 Hz, 2.9 A
240 V~, 50-60 Hz, 2.7 A
* Stryker pays special attention to product improvement and reserves the right to change specifications without notice.
1.2 TECHNICAL SUPPORT
For questions regarding this product, contact the following Technical Service department or your
local representative.
Stryker Medical
1 800 327-0770
3800, East Centre Avenue
Portage, MI 49002
USA
