Stryker FL17E - CPR Emergency Release (Optional); Night Light (Optional); Nurse Call (Optional); 120 V Auxiliary Power Outlet (Offered with 120 V System Only)

Operations Manual
18
2.12 CPR EMERGENCY RELEASE (OPTIONAL)
The CPR emergency release is for emergency use only. When activating the CPR emergency
release, all people and equipment must be removed from the area below and around the head
and foot sections of the bed or serious personal injury or damage to equipment could occur.
If the Fowler and the Knee Gatch are raised and quick access to the
patient is needed, pull outward one of the two CPR emergency release
handles, located under both top corners of the Fowler, to lower the
Fowler and the Knee Gatch to flat position.
N
N
O
O
T
T
E
E
Once the Fowler is completely down, the Fowler motor will reset itself.
During this short period of time -30 seconds - the Fowler switches will
not be available.
2.13 NIGHT LIGHT (OPTIONAL)
The FL17E may be equipped with an optional photoelectric night light to illuminate the floor
area around the bed. The night light turns on as the room lights dim. It is located on the left
side of the frame at the foot end of the bed.
2.14 NURSE CALL (OPTIONAL)
The bed may be equipped with an optional nurse call function allowing the patient to call for
nurse assistance by simply pressing the nurse call red button.
The nurse call module is integrated to both siderail inner control panels, next to the control
switches (see page 14).
Included with this option are two Ø1/4" phono jacks located on both ends of the inner side of the
head casing. The phono jacks enable the use of a nurse call cable which can be placed within
reach of a patient who is not in bed.
An optional cable with a Ø1/4" phono plug enables the linking of the bed to the hospital nurse
call system.
2.15 120V AUXILIARY POWER OUTLET (OFFERED WITH 120V SYSTEM ONLY)
The North American version (120V electrical system) of the FL17E may be
equipped with an optional auxiliary power outlet with a 5A breaker. Located
on the left side at the foot end of the bed, this feature provides nursing staff
with a convenient power source for small electrical equipment.
N
N
O
O
T
T
E
E
Use only equipment with a current consumption of 5 amp or less.
Use only hospital grade electric equipment with the auxiliary power outlet. The use of normal
electric equipment may bring the current leakage to a level unacceptable for an hospital
equipment.
W
W
A
A
R
R
N
N
I
I
N
N
G
G
W
W
A
A
R
R
N
N
I
I
N
N
G
G
