www.stryker.com 6390-009-001 REV B 53
Return To Table of Contents
UNLOADING A PERFORMANCE-PRO COT FROM A VEHICLE (MODEL 6085/6086 WITH THE POWER-
LOAD OPTION)
WARNING
Loading and/or unloading an occupied cot into a vehicle requires a minimum of two (2) trained operators.
1. Lift the vehicle bumper to the raised position (if equipped).
2. Press and hold the release lever at the foot end of the Power-LOAD system and pull to remove the cot from the
vehicle patient compartment.
WARNING
As the cot is unlocked for removal from the vehicle patient compartment, the Power-LOAD lifting arms will slightly raise
the cot. If the lifting arms do not raise the cot, then the operators must be ready to accept the entire weight of the cot
and patient to avoid injury.
3. Grasp the cot frame at the foot end to pull the cot out of the vehicle patient compartment.
Note: The head end lock LED indicators turn solid green only when the cot is ready to unload.
4. Operator 1 (Foot End) − Grasp the cot frame as shown
in Figure 39. Squeeze and hold the cot manual release.
5. Operator 2 (Side) − Grasp the base frame where
indicated in Figure 39, lift slightly, and lower the base
frame to its fully extended position. Verify that the cot
wheels are on the ground.
WARNING
When unloading the cot, ensure that the cot wheels are on
the ground before lowering the arms.
6. Operator 1 (Foot End) − Release the cot manual
release to lock the undercarriage into the extended
position.
Operation Guide
Figure 39
