-18-
Fuses
The following fuse size should be used with the appropriate pump:
Supply Cord Replacement
If the supply cord needs to be replaced, cord selection should be chosen in accordance
with the current involved, surrounding conditions and recommended fuse size. For
information on cable fitting and connection, consult the wiring diagram and cable gland
fitting instructions.
Intermediate Connecting Cord Replacement (Surface Models)
If the intermediate connecting cord between the control module and the pump is to be
changed or is damaged, it must be replaced with a special cord assembly available from
Stuart Turner or one of their approved repairers.
On disassembly note the intermediate cords retention and routing systems and
reassemble to the same pattern.
For information on cable fitting and connection, consult the wiring diagram and cable
gland fitting instructions.
Intermediate Connecting Cord Replacement (Submersible Models)
The intermediate connecting cord (pump supply cord) which connects the pump to the
control module cannot be replaced. If the cord is damaged the pump should be
scrapped.
Cable Gland Fitting Instructions (Pressure Control Module)
The cable gland assembly (Fig. 18 items 1 & 2) provides the necessary protection
against ingress of solid objects and moisture.
The cable retention system is provided by the cable strap assembly (Fig.18 items 3 & 4)
located inside the control module terminal box.
Assembly instructions are as follows:
1. Ensure selected cable sheath diameter is within the permitted range (6 to 9 mm).
2. Strip and prepare cable sheath and insulators as shown in Fig. 19.
3. Disassemble cable gland and strap assemblies and insert cable into position as
shown (Fig. 18) ensuring rubber collar (item 2) is placed over cable before the clamp
nut (item 1) is tightened.
4. Consolidate the stranded conductor ends by twisting, insert and secure in appropriate
terminals - ensuring all
conductor strands are clamped.
Model Fuse Size (Amps)
Diver range 13
Jet range 13
Thame range 13
Loddon range 13
110 Volt models 13
All other models 5
