Studer RCC-03 User Manual

Studer Innotec SA
RCC-02/-03
84 V4.4.0 User manual
Level
User
ref.
Parameter
Unit
12
24
48
Mod.
value
Factory
Min
Max
Factory
Min
Max
Factory
Min
Max
Expert
1298
Increment step of the adaptive low voltage
Vdc
0.1
0
0.4
0.2
0
0.7
0.5
0
1.4
Expert
1121
Battery overvoltage level
Vdc
17
9.5
18.6
34.1
19
37.2
68.2
37.9
74.4
Expert
1122
Restart voltage level after an battery overvoltage
Vdc
16.2
9.5
18
32.4
19
36
64.8
37.9
72
Expert
1140
Floating voltage
Vdc
13.6
9.5
18
27.2
19
36
54.4
37.9
72
Expert
1467
Force phase of floating
-
-
-
-
-
-
-
-
-
Expert
1141
New cycle menu
Expert
1142
Force a new cycle
-
-
-
-
-
-
-
-
-
Inst.
1608
Use dynamic compensation of battery level
(new cycle)
No/Yes
No
-
-
No
-
-
No
-
-
Expert
1143
Voltage level 1 to start a new cycle
Vdc
12.5
9.5
18
25
19
36
49.9
37.9
72
Expert
1144
Time period under voltage level 1 to start a
new cycle
min
30
0
240
30
0
240
30
0
240
Expert
1145
Voltage level 2 to start a new cycle
Vdc
12.3
9.5
18
24.6
19
36
49.2
37.9
72
Expert
1146
Time period under voltage level 2 to start a
new cycle
sec
60
0
600
60
0
600
60
0
600
Expert
1149
New cycle priority on absorption and
equalization phases
No/Yes
No
-
-
No
-
-
No
-
-
Expert
1147
Cycling restricted
No/Yes
No
-
-
No
-
-
No
-
-
Expert
1148
Minimal delay between cycles
hours
3
0
540
3
0
540
3
0
540
Expert
1451
Absorption phase
Expert
1155
Absorption phase allowed
No/Yes
Yes
-
-
Yes
-
-
Yes
-
-
Expert
1156
Absorption voltage
Vdc
14.4
9.5
18
28.8
19
36
57.6
37.9
72
Expert
1157
Absorption duration
hours
2
0.2
18
2
0.2
18
2
0.2
18
Expert
1158
End of absorption triggered with current
No/Yes
No
-
-
No
-
-
No
-
-
Expert
1159
Current limit to quit the absorption phase
Adc
4
1
200
4
1
200
4
1
200
Expert
1160
Maximal frequency of absorption control
No/Yes
No
-
-
No
-
-
No
-
-
Expert
1161
Minimal delay since last absorption
hours
2
0
540
2
0
540
2
0
540
Expert
1452
Equalization phase
Expert
1163
Equalization allowed
No/Yes
No
-
-
No
-
-
No
-
-
Expert
1162
Force equalization
-
-
-
-
-
-
-
-
-
Expert
1291
Equalization before absorption phase
No/Yes
Yes
-
-
Yes
-
-
Yes
-
-
Expert
1290
Equalization current
Adc
60
1
200
60
1
200
60
1
200
Expert
1164
Equalization voltage
Vdc
15.6
9.5
18
31.2
19
36
62.4
37.9
72
Expert
1165
Equalization duration
hours
0.5
0.2
10
0.5
0.2
10
0.5
0.2
10
Expert
1166
Number of cycles before an equalization
25
0
100
25
0
100
25
0
100
Expert
1284
Equalization with fixed interval
No/Yes
No
-
-
No
-
-
No
-
-
Expert
1285
Weeks between equalizations
weeks
26
1
104
26
1
104
26
1
104
Expert
1168
End of equalization triggered with current
No/Yes
No
-
-
No
-
-
No
-
-
Expert
1169
Current threshold to end equalization phase
Adc
4
1
30
4
1
30
4
1
30
Expert
1453
Reduced floating phase
Expert
1170
Reduced floating allowed
No/Yes
No
-
-
No
-
-
No
-
-
