Studer RCC-03 User Manual

Studer Innotec SA
RCC-02/-03
86 V4.4.0 User manual
Level
User
ref.
Parameter
Unit
12
24
48
Mod.
value
Factory
Min
Max
Factory
Min
Max
Factory
Min
Max
Expert
1554
Decrease of the max. current of the source
with input voltage activated by command
entry
No/Yes
No
-
-
No
-
-
No
-
-
Expert
1309
AC input low limit voltage to allow charger
function
Vac
180
100
230
180
100
230
180
100
230
Expert
1433
Adaptation range of the input current
according to the input voltage
Vac
10
5
30
10
5
30
10
5
30
Expert
1553
Speed of input limit increase
50
0
100
50
0
100
50
0
100
Expert
1295
Charge current decrease coef. at voltage
limit to turn back in inverter mode
%
100
0
100
100
0
100
100
0
100
Expert
1436
Overrun AC source current limit without opening
the transfer relay (Input limit)
No/Yes
Yes
-
-
Yes
-
-
Yes
-
-
Basic
1552
Type of detection of the grid loss (AC-In)
Text
Tolerant
-
-
Tolerant
-
-
Tolerant
-
-
Expert
1510
Tolerance on detection of AC-input loss (tolerant
UPS mode)
100
2
120
100
2
120
100
2
120
Expert
1199
Input voltage giving an opening of the transfer
relay with delay
Vac
180
50
230
180
50
230
180
50
230
Expert
1198
Time delay before opening of transfer relay
sec
8
0
30
8
0
30
8
0
30
Expert
1200
Input voltage giving an immediate opening of the
transfer relay (UPS)
Vac
90
50
230
90
50
230
90
50
230
Inst.
1432
Absolute max limit for input voltage
Vac
270
235
290
270
235
290
270
235
290
Expert
1505
Delta frequency allowed above the standard
input frequency
Hz
35
0
35
35
0
35
35
0
35
Expert
1506
Delta frequency allowed under the standard
input frequency
Hz
15
0
15
15
0
15
15
0
15
Expert
1507
Duration with frequency error before opening
the transfer
sec
5
1
5
5
1
5
5
1
5
Inst.
1627
ARN4105 frequency control enable
No/Yes
No
-
-
No
-
-
No
-
-
Expert
1575
AC-IN current active filtering
No/Yes
No
-
-
No
-
-
No
-
-
Inst.
1557
Use an energy quota on AC-input
No/Yes
No
-
-
No
-
-
No
-
-
Inst.
1559
AC-in energy quota
kWh
1
0.5
100
1
0.5
100
1
0.5
100
Expert
1201
AUXILIARY CONTACT 1
Expert
1202
Operating mode (AUX 1)
Text
Automatic
-
-
Automatic
-
-
Automatic
-
-
Expert
1497
Combination of the events for the auxiliary
contact (AUX 1)
Text
Any (Function
OR)
-
-
Any
(Function
OR)
-
-
Any
(Function
OR)
-
-
Expert
1203
Temporal restrictions (AUX 1)
Expert
1204
Program 1 (AUX 1)
Expert
1205
Day of the week (AUX 1)
days
None
None
Every
day
None
None
Every
day
None
None
Every
day
Expert
1206
Start hour (AUX 1)
hh:mm
07:00
00:00
24:00:00
07:00
00:00
24:00:00
07:00
00:00
24:00:00
Expert
1207
End hour (AUX 1)
hh:mm
20:00
00:00
24:00:00
20:00
00:00
24:00:00
20:00
00:00
24:00:00
Expert
1208
Program 2 (AUX 1)
