Flush Inset Panels 1
9
1
6
mm
8 m
m
13
mm
FLUSH INSET PANEL
SPACER
BACKER
DOOR / DRAWER / GRILLE
TOP VIEW
CABINETRY
Illus. A Illus. B
6 mm
REVEAL
8 mm
3 mm
DOOR DOOR
TOP VIEW
13 mm
8 m
m
3 mm
CABINETRY
GRILLE
SIDE VIEW
Illus. C Illus. D
13 mm
2 mm
8 mm
8 mm
4 mm
GRILLE
DOOR
SIDE VIEW
16 mm
4 mm
8 mm
8 mm
2 mm
DOOR
DRAWER
SIDE VIEW
Illus. E Illus. F
8 mm
2 mm
DOOR /
DRAWER
SIDE VIEW
Panel Offsets Illus.
ALL REFRIGERATOR / ALL FREEZER
Door / Grille Sides A
Grille Top C
Grille Bottom / Door Top D
Door Bottom F
OVER-AND-UNDER
Door / Drawer / Grille Sides A
Grille Top C
Grille Bottom / Door Top D
Door Bottom / Drawer Top E
Drawer Bottom F
SIDE-BY-SIDE
Doors (hinge) / Grille Sides A
Doors (handle) Sides B
Grille Top C
Grille Bottom / Door Top D
Door Bottom F
Flush Inset Panels. I
llustrations A–F provide panel
offsets and reveals for all built-in models in a flush inset
application. Refer to the chart below for reference to the
illustrations relating to your specific model.
For additional information on model specific panel
reveals, visit the Specification Library section of our
website, subzerotrade.com.
Flush Inset
subzerotrade.com
