Overlay Panels. I
f you and your client have ordered
an overlay model, you will be adding panels and handles
to give the unit a more custom look. The overlay panel
design option is available for all built-in overlay models.
For exact door panel dimensions, refer to overlay panel
specifications on the following pages.
IMPORTANT NOTE: Overlay models can be used in a
overlay or a flush inset application. Be aware that the
application specified will affect panel sizes, rough
opening dimensions and installation.
The overlay design allows decorative panels to cover the
door trim for a more seamless appearance that blends
with the design of the room. The most common way to
achieve this look is to work with three panels—the deco-
rative overlay panel which is typically 19 mm, a 3 mm
spacer panel and a 6 mm backer panel. Depending on
your cabinet manufacturer, this could also be one panel
routed for different dimensions.
Regardless of the physical construction of the panels
(three-panel assembly or routed panel), you will need to
follow the overlay panel specifications on the following
pages for exact sizing and panel placement to ensure a
proper fit.
Custom cabinet overlay panels can be combined with
unique hardware for design flexibility. Shown with curved
handle option to compliment Wolf E Series ovens.
Overlay Panel Requirements
MAX WEIGHT PER PANEL
ICBBI-36R, ICBBI-36RG and ICBBI-36F 34 kg
All Other Overlay Models 23 kg
Grille Panel 6 kg
MIN PANEL THICKNESS
All Overlay Panels 16 mm
Overlay
