Sub-Zero CBBI-36R - Door Clearance

Model Specifications 8
The doors of all built-in models open to a maximum of 110°.
A 90° door stop is shipped with all units. For additional
information, refer to the full-scale templates at the end of this
guide. The handle depth reflects the tubular, curved and pro
handles.
IMPORTANT NOTE: For flush inset applications, add 13 mm
to dimension (A).
Door Clearance
All Refrigerator / All Freezer Models Over-and-Under Models Side-by-Side Models
6
06
mm
BEHIND
FRAME
A
C
60 mm
BA
C
60 mm
6
06
mm
BEHIND
FRAME
6
0
mm
CD
6
0
mm
6
06
mm
BEHIND
FRAME
A
Interior Capacity / Weight
Refrigerator (R) and freezer (F) interior capacities are listed in
liters. Shipping weights (W) are listed in kilograms and are
based on stainless steel models.
Door Clearance
ALL REFRIGERATOR / ALL FREEZER AC
ICBBI-36R, ICBBI-36RG, ICBBI-36F 946 mm 432 mm
OVER-AND-UNDER ABC
ICBBI-30U, ICBBI-30UG 796 mm 600 mm 368 mm
ICBBI-36U, ICBBI-36UG 946 mm 600 mm 432 mm
SIDE-BY-SIDE ACD
ICBBI-36S 565 mm 260 mm 216 mm
ICBBI-42S, ICBBI-42SD 668 mm 318 mm 222 mm
ICBBI-48S, ICBBI-48SD 762 mm 356 mm 248 mm
Capacity / Weight RFW
ICBBI-36S 346 L 227 L 244 kg
ICBBI-42S 455 L 227 L 264 kg
ICBBI-42SD 452 L 230 L 276 kg
ICBBI-48S 532 L 269 L 286 kg
ICBBI-48SD 530 L 272 L 298 kg
Capacity / Weight RFW
ICBBI-36R 660 L 191 kg
ICBBI-36RG 665 L 195 kg
ICBBI-36F 646 L 184 kg
ICBBI-30U 361 L 116 L 210 kg
ICBBI-30UG 367 L 116 L 216 kg
ICBBI-36U 450 L 148 L 234 kg
ICBBI-36UG 447 L 142 L 240 kg
