Dual Installations 3
0
Dual Installation Kit with Dual Wide Grille.
This kit will replace the existing grilles that ship with the
units and span the entire width of both units. The kit
includes a 6 mm center trim strip (required for proper
installation of the dual wide grille), heater, dual kickplate
and mounting hardware. Dual wide grilles are available for
all built-in models and design applications. The overlay
dual installation kit with grille will accept overlay and dual
flush inset panels. For dual wide grille panel dimensions,
refer to the panel specifications below for your design
application. Grille panel dimensions listed are for a
standard 2134 mm overall height of the unit.
Dual Installation Kit. T
his kit is available for those
who choose to utilize the individual grilles that ship with
each unit. The kit includes a 6 mm filler strip (which fills
the reveal between the units and grilles), heater and
mounting hardware. This dual installation kit is not
required if a custom filler strip is used. The filler strip
should be a minimum of 51 mm wide. Refer to the full-
scale template on page 35 for more information.
Two 762 mm Models
DUAL WIDE GRILLE WH
Overlay Panel 1530 mm 235 mm
Spacer Panel 1508 mm 211 mm
Backer Panel 1524 mm 227 mm
Two 914 mm Models
DUAL WIDE GRILLE WH
Overlay Panel 1835 mm 235 mm
Spacer Panel 1813 mm 211 mm
Backer Panel 1829 mm 227 mm
Dual Wide Grille—Overlay Panels
Two 762 mm Models
DUAL WIDE GRILLE WH
Flush Inset Panel 1556 mm 235 mm
Spacer Panel 1508 mm 211 mm
Backer Panel 1524 mm 227 mm
Two 914 mm Models
DUAL WIDE GRILLE WH
Flush Inset Panel 1861 mm 235 mm
Spacer Panel 1813 mm 211 mm
Backer Panel 1829 mm 227 mm
Dual Wide Grille—Flush Inset Panels
Dual Installations
