Full-Scale Templates
TOP VIEW
DOOR CLOSED
DOOR OPEN 110˚
FILLER STRIP
M
AIN FRAME
A
LLOW FOR FILLER LAP
B
EHIND FLANGE
APPROX PROFILE OF
STAINLESS STEE WRAPPED
DOOR AND HANDLE
S
UB-ZERO UNITSUB-ZERO UNIT
OVERLAY PANEL
19 mm THICK
(TYPICAL)
6
m
m
P
AN
EL
3
2
m
m
P
AN
E
L
1
9
m
m
P
A
N
EL
1
3
m
m
P
A
N
EL
2
5
m
m
P
A
N
EL
51 m
m
APPROX THICKNESS OF
WRAPPED STAINLESS
STEEL DOOR
This full-scale template
shows the panel and handle
profile for a dual installation
with a 51 mm filler strip at
110˚ door opening.
Interference of door panels
with handles at maximum
door opening may require
the use of an optional 90˚
door stop available through
your Sub-Zero dealer.
Panel and Handle Profile—110° Door Opening 3
