北米Model "A1760BE-A" EDITED: 2020/ 10/ 1
(4) Pull out the glove box horizontally
and remove the hinge portion. When
doing this, be careful not to damage
the hinge.
2. Remove the cabin air filter according to
the following procedure in order to prevent
dust on the air cleaner from falling to the
inside of its housing.
(1) Push in the four stoppers to unlock,
and then slowly pull out the filter 4 in
(10 cm) from the housing.
(2) Completely pull out the filter by
gently tilting the front side of the filter
downward.
3. Replace the cabin air filter element
with a new one.
CAUTION
The arrow mark on the filter must
point UP.
Climate control/Air filtration system
4-12
