北米Model "A1760BE-A" EDITED: 2020/ 10/ 1
! Type F clips
S11BI010206
Insert the clip without the head first and
then push the head of the clip into the hole.
Engine hood
S11AC
To open the hood:
1. If the wiper blades are lifted off the
windshield, return them to their original
position.
2. Pull the hood release knob under the
instrument panel.
3. Release the secondary hood release
by moving the lever between the front grille
and the hood toward the left.
4. Lift up the hood.
To close the hood:
1. Lower the hood to a height of approxi-
mately 11.8 in (30 cm) above its closed
position and then let it drop.
2. After closing the hood, be sure the
hood is securely locked.
If this does not close the hood, release it
from a slightly higher position.
WARNING
Always check that the hood is
properly locked before you start
– CONTINUED –
Maintenance and service/Engine hood
11-9
11
To Next Page
