北米Model "A1760BE-A" EDITED: 2020/ 10/ 1
& Components that will operate with the seatbelt pretensioner(s) simultaneously
S01AF10
Cases
Frontal collision
Side collision Rollover accident
Components
Offset frontal collision Other frontal collision
Seatbelt pretensioner for driver * * *
*2*3
*
Shoulder belt pretensioner for front passenger * * *
*3*4
Lap belt pretensioner for front passenger * *
— —
SRS frontal airbag
For driver * *
For front passenger
*1
* *
SRS curtain airbag
Impacted side * — * *
Non-impacted side * — — *
SRS side airbag
Impacted side — — *
*5
—
Non-impacted side — — —
—
*: Operate
–: Not operate
*1: This does not operate if the occupant detections system deactivates airbag operation.
For details, refer to “Front passenger’s SRS frontal airbag” F1-45.
*2: This operates when both the satellite safing sensor and driver’s side front door impact sensor sense an impact force.
*3: These do not operate when a center pillar impact sensor detects a signal faster than the front door impact sensor, or both sensors detect signals
simultaneously.
*4: This operates when both the satellite safing sensor and the front passenger’s side front door impact sensor sense an impact force.
*5: This operates when both the satellite safing sensor and any of the center pillar impact sensors/front door impact sensors sense an impact force.
– CONTINUED –
Seat, seatbelt and SRS airbags/Front seatbelt pretensioners
1-19
